Description
System Specifications
HIGH FREQUENCY GENERATOR
20 KHz High Frequency technology
30 kW rating
Technique selection
kVp range: 40 – 125, in 1 kV increments
mA stations: 50s, 100s, 100L, 300L
Digital kVp, mA, and mAs readout
Tilt-out control panel
Built-in tube protection and self diagnostics
Adjustable volume, audible exposure signal
Automatic generator “Shut Off” circuit
Tilt-out control panel
UL classified
TABLE / TUBESTAND
Enclosed, integrated radiographic table Stationary table top: 53 in. x 24 in.
Welded base construction Transformer mounting shelf Grid cabinet with cassette tray
Grid cabinet / tubestand interlock Grid 8:1 ratio, 103 LPI Animal restraining device Angulation dial and deluxe operator handgrips Tubestand handles
X-RAY TUBE
1.0-2.0 mm F.S., 140,000 H.U. with 90° horns
CABLES
12 ft. high voltage cables with federal terminations
COLLIMATOR
Manual collimator with light field and swivel mount Field light “on” time – selectable 30, 60 seconds
Upgrade Options
- Four-way float top table, 67 in. x 32 in.
- Two-way float top table, 58 in. x 32 in.
- Anatomical programmed technique selection
